1. Product overview
Dual stream series av access best 4k kvm over ip extender is a FPGA-based architecture, lossless quality,
sub-frame delay distributed seat all-in-one machine. EXQ.S codec technology with extreme image quality
and standard H.264/H.265 codec technology are embedded with their own privacy protocol to ensure that
signals are protected during signal transmission. Converged communication, cross-region optical fiber transmission,
multi-level interconnection, cross-switch, cross-segment can achieve stable signal transmission.
2. Technical specifications
| project | parameter |
| video input | HDMI2.0 x1: 4096x2160@60Hz, backward compatible |
| video output | HDMI2.0 x1: 4096x2160@60Hz, backward compatible |
| Video loop out | and HDMI output multiplexing: input mode do loop out, support hard loop out |
| audio input | HDMI embedded audio Single-ended stereo x1: 3.5 Phoenix terminal x3 |
| audio output | HDMI embedded audio Single-ended stereo x1: 3.5 Phoenix terminal x3 |
| serial port | RS-232 x1 /RS-485 x1: 3.5 Phoenix terminal x3 |
| relay | 24V weak current relay x1: 3.5 Phoenix terminal x2 |
| I/O | 5V x 4: 3.5 Phoenix terminal x5 |
| infrared | and I/O multiplexing |
| USB | USB2.0 host port x1: red USB2.0 Host Port x2: Black USB2.0 transparent transmission dedicated host port x1: green |
| network | 1000M RJ45 x1 1G SFP x1 |
| power supply | POE:802.3at DC12V / 3A |
| Video coding performance | EXQ.S:4096x2160@60Hz x1 H.265:4096x2160@60Hz x1 + 2048x1080@60Hz x1 + 1024x540@30Hz x1 JPEG:1024x540@30Hz x1 |
| Video decoding performance
| EXQ.S:4096x2160@60Hz x1 / 2048x1080@60Hz x4 H.265:4096x2160@60Hz x1 / 2048x1080@60Hz x4 |
| audio codec | 48K sampling, PCM, G.711, AAC |
| USB | all USB devices |
| KVM | Visual OSD support Support Rights Management Support 1 keyboard and mouse cross-system Support for large screen monitoring and operation Support inter-agent collaboration |
| liquid crystal | white OLED Support displaying IP, input signals, device status, etc. |
| Integrated dialing | Top: RX output Bottom: TX input |
| network hot standby | optical-electrical |
| POE/DC power supply hot standby | support |
| Product name | av access best 4k kvm over ip extender |
3. wiring instructions for av access best 4k kvm over ip extender:
